Reliability and performance
Print speeds up to 556 cps at 12 cpi and a rugged design that can handle extreme environments and workloads help you to be productive no matter where you are.
Flexible paper handling
Easily switch between push and pull feeds and print on multiple types of media, including single-part or multi-part continuous forms, sheet-fed paper, and single-part or multi-part cut forms.
Easy to use
The easy-to-use operator panel lets you access all of the printer functions, monitor character and page counts and preview fonts.
High-quality and long lasting
Print near letter-quality multi-font documents and replace supplies less often. Powerful printheads last up to 300 million characters and re-inking ribbons that print up to 8 million characters are available.
Optional 8 million characters (draft mode at 10 cpi)-
Standard 4 million characters (draft mode at 10 cpi) -
Packaged Size (mm - H x W x D)
325 x 609 x 408 mm
Packaged Weight, kg
Size (mm - H x W x D)
195 x 492 x 290 mm
1-Year Onsite Service, Next Business Day
UL 60950-1, CSA, FCC Class B, VCCI, CB IEC 60950-1,
FMedia Types Supported
Multi-part forms - Up to 1+5 Parts
(up to 0.51 mm paper thickness).
Single-part forms - 60 to 90 gsm
(0.11 mm paper thickness).
Forms or Paper - 60 to 90 gsm
(0.11mm maximum paper thickness).
Single-part or multi-part continuous forms
(254mm maximum page width, 76mm minimum
page width, 559mm maximum page length, 7 mm
minimum page length).
Narrow sheet fed paper (215mm maximum page
width, 105mm minimum page width, 559mm
maximum page length, 139mm minimum
Single-part or multi-part cut forms (297mm maximum
page width, 76mm minimum page width, 559mm
maximum page length, 76mm minimum page length).
Optional Local Ports
Internal RS-232C serial
Printer Languages (Standard)
Personal Printer Data Stream (PPDS)
24-Pin Dot Matrix
Up to 556 cps Fast Draft @ 12 cpi
Up to 480 cps Draft @ 12 cpi
Up to 160 cps Near Letter Quality @ 12 cpi
Maximum Print Line (mm)
360 x 360 dots per inch
Paper Handling Standard
Front Tractor Feeder
Optional Paper Handling
Automatic Sheet Feeder (narrow)
Tractor 2 (narrow)
